"jupiter aircraft" company

was established in 2014 by an engineer Stefan Raab, who has long worked in Germany for the “Airbus” Company.

The aircraft “Jupiter-J4S” was created by a team of German engineers under the direction of Stefan Raab, who set the task to create the world’s best 4-seater aircraft with the powerful new engine ROTAX 915iS. In order to reduce the cost of production, it was decided to arrange assembly of the aircraft in partnership with the “KTD GROUP” in Kanev, Ukraine. We have decided to replace expensive and often unnecessary avionics with a comfortable iPad PRO 12,9 inches with advanced software installed ForeFlight and Air Nav Pro, also arranged assembly in Ukraine and sales without intermediaries, dealers, we achieved prices several times lower than those of competitors. At the moment, the project is fully completed, and the first three aircraft Jupiter-J4S prepared for release at the end of 2019 will begin flight tests. Orders for delivery are accepted at the end of 2019. In the world there are many unique 4-seater aircraft such as the Cessna 172, 182, 400; Cirrus 20, SR22; Mooney Bravo; Piper Archer; Beech Bonanza; Socata Tobago, and nevertheless, even the closest in characteristics Diamond DA 40 4-seater aircraft; Pipestrel Panthera; Cetus 1000, RV-10; Dynaero MCR 4S; Flight Design C4; Tecnam P 2010 cannot match the efficiency of Jupiter J4S, primarily, thanks to its unique aerodynamic design and powerful, efficient engine Rotax 915iS. The cockpit is equipped with two Ipad Pro 12,9” with ForeFlight and Air Nav Pro the world’s best software, the central display 7” Dynon-120. In addition, an escape system, autopilot, valve control PC and an up-to-date device in small aircraft – AOA, allowing unskilled pilots to make a safe landing on a small airfield – are standard equipment. Exceptional safety for pilots and passengers is an integral part of the Jupiter Company policy. Therefore, Jupiter J4S is equipped with a ballistic parachute and fire-proof fuel tanks, as well as inertial coil holder and shoulder straps, which can lock during turbulence. The cockpit is equipped with heating system, and a landing gear sensor is installed. For additional protection, the cockpit is reinforced with carbon.

Technical characteristics of the Jupiter-J4S

Number of places

Engine

Rotax 915iS (135l.s.)

Fuel Type

A-95

Screw

3 blade, VAR Woodcomp

Chassis

3 rack, retractable hydraulic

Wheels and Brakes

Beringer

Maximum flight weight

820 kg

Empty weight

370 kg

The volume of fuel tanks

117 liters

Wing area

10,8 m2

Wingspan

9,6 m

Aircraft length

7,2 m

Height

2,65 m

Fuselage width MAX

1,35 m

Cabin height

1,2 m

Cabin length MAX

3,0 m

Wing loading

80 kg / m2

Track chassis

2,15 m

Wheel size

450 mm

Luggage space

300 liters

Aerodynamic quality MAX

Cruising speed

275 km/h

Max Speed

310 km/h

Landing speed

75 km/h

Rate of climb

4,5 m/s

Run

250 m

Mileage

150 Meter
